MIM-72
Suspended armaments
OLD‑WIKI.WARTHUNDER.COM (DEFUNCT)
Description
The MIM-72 is a US Surface to Air missile that can be found on the Imp.Chapparal in the american and israeli tech tree. The Missile comes in 4 variants: The american chapparal features the MIM-72C and E while the israeli has acces to the MIM-72E and G variants.
Vehicles equipped with this weapon
General info
| Missile characteristics | |
|---|---|
| Calibre | 127 mm |
| Mass | 86.3 kg |
| Guidance | IR, Rear-Aspect |
| Maximum speed | 720 m/s |
| Maximum overload | 16.5 G |
| Firing range | 6 km |
| Missile guidance time | 60 secs |
| Explosive mass | 4.31 kg TNTeq |
| Fuse delay | 1 m |
| Fuse sensitivity | 0.3 mm |
| Trigger radius | 5 m |
Effective damage
Describe the type of damage produced by this type of missile (high explosive, splash damage, etc)
Comparison with analogues
The MIM-72 is similar to the american FIM-92 Stinger missile and the soviet 9M37M missile.
Usage in battles
The MIM-72's effectiveness highly depends on the target and its orientation relative to the launcher. Due to the MIM-72's low G overload it is best used against slower, less agile and distant targets. Though not very effective against distant helicopters, the missile has a very sensitive IR seeker and can detect almost anything.
Pros and cons
Pros:
- The MIM-72E and G variants are smokeless, making them harder to be spotted by enemy aircraft
- Features relatively good flare resistance
- Has a high explosive mass, knocking out most planes with a direct hit
Cons:
- Low all-aspect range
- Limited overload making close-range hits almost impossible
